Reviews for WiiM Mini

Which WiiM product is right for you?

Audio Amplification	-	-	-	-	TI TPA3255	TI TPA3255	2 x TI TPA3255
Main Purpose	Connected to amplifier or powered speaker for streaming	Connected to amplifier or powered speaker for streaming	Connected to amplifier or powered speaker for streaming	Connected to amplifier or powered speaker for streaming	Connected to passive speaker for streaming	Connected to passive speaker for streaming	Stream music and power your passive speakers
Pair with a Sub	-	-	-	Y	Y	Y	Y
USB Port (Storage/Audio Out)	-	-	-	Y	Y	Y	Y
Wireless Connectivity	Wi-Fi 5, BT 5.0	Wi-Fi 5, BT 5.0	Wi-Fi 5, BT 5.0	Wi-Fi 6, BT 5.3 (Will be upgraded to Wi-Fi 6E via software update)	Wi-Fi 5, BT 5.0	Wi-Fi 6, BT 5.3 (Will be upgraded to Wi-Fi 6E via software update)	Wi-Fi 6, BT 5.3 (Will be upgraded to Wi-Fi 6E via software update)
Ethernet	-	Y	Y	Y	Y	Y	Y
DAC IC	TI PCM 5121	TI PCM 5121	AKM 4493SEQ	ESS ES9038 Q2M	ESS 9018 K2M	ESS ES9038 Q2M	ESS ES9039 Q2M
Analog Out SNR	106 dB	106 dB	121 dB	121 dB	108 dB	120 dB	120 dB
THD+N (Analog Out)	-92dB (0.0025%)	-92dB (0.0025%)	-113dB (0.00023%)	-116 dB (0.00015%)	-92dB (0.0025%) at 5W	-105 dB (0.0005%) at 5W	-106 dB (0.0005%) at 5W
Analog Input (ADC)	Fixed 48k, 16 bit	Fixed 48k, 16 bit	Up to 192k, 24 bit	Up to 192k, 24 bit	Up to 192k, 24 bit	Up to 192k, 24 bit	Up to 192k, 24 bit
Google Cast Audio	-	Y	Y	Y	Y	Y	Y
Group with Nest speakers and Display	-	Y	Y	Y	Y	Y	Y
Group with Echo speakers and Display	Y	Y	Y	Y	Y	Y	Y
Alexa Multiroom with UHD	-	Y	Y	Y	Y	Y	Y
Group with HomePods	Y	Y	Y	-	Y	-	-
Works with Alexa	Y	Y	Y	Y	Y	Y	Y
Works with Google	-	Y	Y	Y	Y	Y	Y
Works with Siri	Y	Y	Y	-	Y	-	-
Group with WiiM or Linkplay devices	Y	Y	Y	Y	Y	Y	Y
AirPlay 2	Y	Y	Y	-	Y	-	-
2-Way Bluetooth	Y	Y	Y	Y	Y	Y	Y
Roon Ready	-	Y	Y	Y	Y	Y	Y
DLNA	Y	Y	Y	Y	Y	Y	Y
Spotify Connect & TIDAL Connect	Y	Y	Y	Y	Y	Y	Y
Gapless Playback	Y	Y	Y	Y	Y	Y	Y
10-band Graphics EQ	Y	Y	Y	Y	Y	Y	Y
Linkplay Music Streaming Platform	Y	Y	Y	Y	Y	Y	Y
CPU	Dualcore A7	Quad Core A53	Quad Core A53	Quad Core A53	Quad Core A53	Quad Core A53	Quad Core A53
DRAM	128 MB	512 MB	512 MB	512 MB	512 MB	512 MB	512 MB
Flash	128 MB	512 MB	512 MB	512 MB	512 MB	512 MB	512 MB
Audio Input Port	AUX 3.5mm jack	Line-in, Optical	Line-in, Optical	HDMI ARC, Optical, Line, Phono, USB Disk	HDMI ARC, Line In, Optical, USB Disk	Line, Optical, HDMI ARC, USB Disk	HDMI ARC, Optical, Line, USB Disk
Audio Output Port	AUX 3.5mm jack, Optical	Line-Out, Optical, Coax	Line-Out, Optical, Coax	RCA, Optical COAX, USB, Headset	Banana (x2), Subwoofer, USB	Banana (x2), Subwoofer, USB	Banana (x2), Subwoofer, USB Audio

FAQs

How is WiiM Mini different from other wireless audio receivers?

The WiiM Mini is super easy to setup and supports the High-Res audio streaming via WiFi. It gives you the ability to play contents via Apple Airplay 2 and Spotify/TIDAL connect. It could be grouped with other Airplay 2 or Alexa devices to play in a group for wireless multi-room audio. It supports popular music services via its user friendly device companion App. It also has the analog audio input so you could connect your audio device and listen it on multiple devices.

Can I use multiple WiiM Mini devices to build a wireless whole house sound system？

Yes, WiiM Mini supports Airplay2 so you could group it with other Airplay2 devices. You could also group them with your other Alexa enabled devices (i.e., Echo) using your Alexa App. In addition, you can group multiple devices in WiiM Home App to build a wireless whole house sound system easily.

Can I use voice to control WiiM Mini?

Yes, the WiiM Mini can be voice-controlled using Amazon Alexa and Apple Siri when connected over Wi-Fi to a voice-enabled devices (such as the Echo, iPhone or Homepod etc.).

Can the WiiM Mini be calibrated so there is no lag to other Apple Airplay 2 speakers?

The WiiM Mini supports auto calculation of its audio latency via its built-in microphone that enables it to play in sync with other Apple Airplay 2 speakers.

Can I watch video from Netflix and Youtube on my phone, tablet or PC and listen audio on the WiiM Mini?

You could watch video on your phone and tablet and listen on your favorite speakers/soundbar via Airplay2.

Does WiiM Mini support changing EQ settings like bass and treble?

Yes, you can change EQ settings in WiIM Home app to get better listening experience.

High-Res Audio

WiiM audio devices provide the capability to play Hi-Res lossless audio content from Spotify, Amazon Music, TIDAL, Deezer, Qobuz, and more. It supports up to 192kHz, 24-bit audio output which is the same as artist recordings in the studio. The integrated TI stereo DAC provides high-quality analog audio output with 106-dB SNR, dynamic range, and -92dB THD+N performance, outstanding in all audio categories.

MP3

High Quality

320 Kbps

CD(HI-FI)

Lossless Quality

1411 Kbps

HI-RES

High-Res Quality

2304-9216 Kbps

Gapless Playback

Precise gapless playback is important to your listening experience. With precise gapless playback, the playback timing is guaranteed to be identical to the source. There are no gaps or overlaps (crossfading) between successive tracks. The gap will be very noticeable in " continuous " music such as live concert recordings, some classical music, etc.

Adaptive EQ

Breakthrough listening experience requires both high-res audio content and a high-quality playback device . When adaptive EQ is enabled, the music genre information and other tags included in the audio content are used to adjust the frequency in real time by bringing in rich audio to capture every music detail or make human voices clearer in the podcast.

Auto calibration of audio delay

The connected receiver or speaker may have different audio path latency due to different hardware, software and DSP processing. To maintain the synchronization of each system, it's desirable to measure the audio path delay automatically. By leveraging the on-device microphone and proprietary algorithm, the entire audio path latency is measured automatically when it's connected with the receiver or speaker. The latency value will be used to maintain the perfect audio synchronization in wireless multi-room or multi-channel playback.

Learn how to setup your device

Wi-Fi Connection

Using WiIM Home app to set up
Using AirPlay to set up
Using iOS Home App to set up

Multi-room Audio

Group with another WiiM Mini
Group with Echo or other Amazon products
Stereo Pairing with another WiiM Mini

Spotify Connect
Tidal Connect
Airplay 2

Using WiIM Home app to set up

Open the WiiM Home app.
Press the button on your device until the LED is white and blinking.
Tap the "Set up" button on the popup showing your device.
Follow the steps in the App to set up your device.
See the video on the right for more detailed information.

Using AirPlay to set up

Open WiiM Home app.
Press the button on your WiiM Mini until the LED is white and blinking.
Enter Settings -> Wi-Fi screen on your iPhone
Select your unit as the AirPlay speaker in the Wi-Fi screen.
Follow the steps in the Wi-Fi screen to set up your device.

Using iOS Home App to set up

Open WiiM Home app.
Press the button on your device until the LED is white and blinking.
Open the Home app and tap Add Accessory or Scan Accessory.
Please tap yellow "More options...?".
Tap your device which MUST be listed under "Select an Accessory to Add to you".
Tap the "Allow" to allow your device to connect with your Wi-Fi network.

Group with another WiiM Mini

Open WiiM Home app.
Select the device and click the plus sign in the upper right corner
Select the other WiiM Mini, and then click "Done".

Group with Echo or other Amazon products

Open the Amazon Alexa app and log into the same Amazon account as the WiiM Home app.
Open Devices .
Select Plus and then select Combine Speakers.
Select Multi-room music.
Follow the instructions in the app to complete the setup.

Stereo Pairing with another WiiM Mini

Open WiiM Home App.
Group two or more WiiM Mini together.
Click the button to choose the device channel to "L/R/LR"

Spotify Connect

Open your Spotify app.
Play a song and select Devices Available.
Select your device and start listening.
Go to spotify.com/connect to learn how.

Tidal Connect

Open the 'Now Playing' screen while playing a song.
Go to device selector on the bottom left.
Choose a Tidal Connect-enabled device.
Go to tidal.com/connect to learn how.

Airplay 2

Open the Control Center on your Apple device.
Tap and hold the audio card in the top-right corner of the screen, then tap the AirPlay .
Select your speaker.
